Clerestory Barn: Timber Frame Specialty Barns
Specialty Barn Building Kits: The Clerestory
The Clerestory Barn is our answer to a unique need: a beautiful barn with high enough clearance to store RVs. Featuring a 20’ mainframe and 14’ of clearance from the finished floor to the ceiling joist, this barn offers an ideal solution for vacation vehicle storage or other tall items. Inspired by Connecticut’s historic tobacco barns and enhanced with a naturally-lit clerestory design, this timber loft barn combines functionality with elegant design. Whether used for storage, a workshop, or a unique living space, the Clerestory Barn makes a striking addition to any property.
37′ x 48′ Clerestory barn shown with optional overhead door by others, swing-out doors and bow top window.
Our Basic Kit Includes
- Pre-cut pressure treated sills
- Pre-cut post & beam frame
- 8×8 / 6×6 posts*
- 8×8 / 6×8 carrying beams*
- 3×4 girts and braces
- 2×10 rafters
- 2×8 collar ties
- Kiln dried premium siding*
- Kiln dried roof sheathing*
- (1) 42″ Walk-out door kit with oak latch & 16″ pintle hinges
- (4) 8′ transom windows
- (4) 6′ transom windows
- (2) Gable vents
- 12D, 16D and 40D Framing nails
*Eastern White Pine
Available Sizes
- 37′ x 36′ 40′ x 36’
- 37′ x 48′ 40′ x 48’
- 37′ x 60′ 40′ x 60′ *
*Larger sizes available, please contact us to make special request
Section Through
NOTE: Photos shown may contain nonstandard accessories that are not provided by Post and Beam Barns by Country Carpenters.
A Look at Some of Our
Clerestory Barns
Start Your Project with Our Handcrafted Kits
Click below to start the process and get in touch with one of our client advisors. Soon you’ll be on your way to owning your very own Country Carpenters Clerestory Barn.
